2 x 1/2 x 1/4 Inch Neodymium Rare Earth Double-Sided Countersunk Block Magnets N42 (4 Pack)
27.6 lbs Pull Force
2 x 1/2 x 1/4 Inch Neodymium Rare Earth Double-Sided Countersunk Block Magnets N42 (4 Pack)
$33.15
Buy More and Save up to 30%
| Quantity of Packs | Price per Pack | Discount |
|---|---|---|
| Buy 2 | $31.49/pack | 5% Off |
| Buy 3 | $29.84/pack | 10% Off |
| Buy 5 | $28.18/pack | 15% Off |
| Buy 10 | $26.52/pack | 20% Off |
| Buy 25 | $24.86/pack | 25% Off |
| Buy 50 | $23.21/pack | 30% Off |
Need more than 50 sets? Email us for a quote.
Magnet Specifications
Size
:
2.00 x 0.50 x 0.25 Inch (Length x Width x Thickness)
Metric Size
:
50.8 x 12.7 x 6.35 mm (Length x Width x Thickness)
Countersunk Hole Size
:
0.295 x 0.17 Inches at 82° - 1 Inches Apart
Screw Size
:
#6
Material Grade
:
N42
Pull Force
:
27.6 lbs
Coating
:
Nickel-Copper-Nickel (Ni-Cu-Ni)
Magnetization Direction
:
Thickness
Magnet Material
:
Sintered Neodymium (NdFeb)
Tolerance
:
+/- 0.004 Inches
Maximum Operating Temperature
:
80°C / 176°F
Flux Density
:
13,300 Gauss
Part Number
:
BDCS2X12X14N42-4PK
Quantity Included
:
4 Countersunk Block Magnets
Magnet Safety Warning
Please handle these rare earth 2 x 1/2 x 1/4 inch block magnets with caution. They are incredibly strong and powerful for their small size, and can pose a safety risk.
These grade N42 block magnets are difficult to separate by hand, and can snap back together with extreme speed and force. This may cause the magnets to break and send small fragments flying into the air, potentially causing injury.
With 27.6 lbs of pull force, these block magnets can also pinch your fingers if they snap back together. For your safety, keep these magnets far apart and at a safe distance of several feet or more once separated. Hand and eye protection is strongly recommended when handling these magnets.
