1/2 x 1/2 x 1/8 Inch Neodymium Rare Earth Countersunk Block Magnets N52 (24 Pack)

6.85 lbs Pull Force

1/2 x 1/2 x 1/8 Inch Neodymium Rare Earth Countersunk Block Magnets N52 (24 Pack)

$25.99
  • $ 25.99 USD



Buy More and Save up to 30%
Quantity of Packs Price per Pack Discount
Buy 2 $24.69/pack 5% Off
Buy 3 $23.39/pack 10% Off
Buy 5 $22.09/pack 15% Off
Buy 10 $20.79/pack 20% Off
Buy 25 $19.49/pack 25% Off
Buy 50 $18.19/pack 30% Off
Need more than 50 sets? Email us for a quote.



Magnet Specifications

Size : 0.50 x 0.50 x 0.125 Inch (Length x Width x Thickness)
Metric Size : 12.7 x 12.7 x 3.175 mm (Length x Width x Thickness)
Countersunk Hole Size : 0.242 x 0.136 Inches at 90°
Screw Size : #4
Material Grade : N52
Pull Force : 6.85 lbs
Coating : Nickel-Copper-Nickel (Ni-Cu-Ni)
Magnetization Direction : Thickness - Pair
Magnet Material : Sintered Neodymium (NdFeb)
Tolerance : +/- 0.004 Inches
Maximum Operating Temperature : 80°C / 176°F
Flux Density : 14,800 Gauss
Part Number : BCS12X12X18N52-24PK
Quantity Included : 24 Countersunk Block Magnets


Sold in Matched Pairs
Each set of countersunk block magnets includes 12pcs with the countersunk hole on the north pole, and 12pcs with the countersunk hole on the south pole. This allows you to pair them together to create magnetic latches, fasteners, and other closure mechanisms. Both the north and south poles will be attracted and attach to anything metal.

If you need the magnets in a different configuration, please contact us.


Drill Torque Information
It is very easy to overtighten and break/crack countersunk neodymium magnets when screwing them in place. We recommend hand tightening when possible. If using a drill, start with a low torque setting and work your way up.


Customer Reviews

Based on 2 reviews
100%
(2)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
A
Aidan K. (Chicago, United States)
AMAZING DEAL, HIGH QUALITY

These simply cannot be beat for the price. Can hold a surprisingly large amount with just 1. Great for hanging tools and kitchenware on the wall or french cleat systems. Will buy again 1000%.

B
Buzz (Burnsville, United States)
Such great magnets

I use these and others, mostly countersunk discs all over my shop. They've become indispensable for the convenience of having designated places for magnet-friendly tools and writing implements. Having multiple rulers, box cutters, pens, pencils at every work station kept secure but easily removed and replaced has saved thousands of steps and frustration looking for things that didn't have designated places. Latest project: a removable arm that magnetically holds my Kindle upside down at the perfect reading angle while lying prone on my back. TotalElement is a class act with real-person support for information.
