Learning Center1/2 x 1/4 x 1/32 Inch Thin Neodymium Rare Earth Block Magnets N52 (100 Pack)
1/2 x 1/4 x 1/32 Inch Thin Neodymium Rare Earth Block Magnets N52 (100 Pack)
| Quantity of Packs | Price per Pack | Discount |
|---|---|---|
| Buy 2 | $24.22/pack | 5% Off |
| Buy 3 | $22.95/pack | 10% Off |
| Buy 5 | $21.67/pack | 15% Off |
| Buy 10 | $20.40/pack | 20% Off |
| Buy 25 | $19.12/pack | 25% Off |
| Buy 50 | $17.85/pack | 30% Off |
| Buy 100 | $16.57/pack | 35% Off |
Magnet Specifications
| Imperial Size | 0.50 x 0.25 x 0.03125 Inch (Length x Width x Thickness) |
|---|---|
| Metric Size | 12.7 x 6.35 x 0.794 mm (Length x Width x Thickness) |
| Material Grade | N52 |
| Pull Force | 1.15 lbs |
| Coating | Nickel-Copper-Nickel (Ni-Cu-Ni) |
| Magnetization Direction | Thickness |
| Magnet Material | Sintered Neodymium (NdFeB) |
| Tolerance | +/- 0.004 Inches |
| Max Operating Temperature | 80°C / 176°F |
| Surface Field | 1,292 Gauss |
| Flux Density (Br) | 14,800 Gauss |
| Magnet Weight | 0.5 Grams |
| Part Number | B12X14X132N52-100PK |
| Quantity Included | 100 Block Magnets |
Produced in an ISO 9001 Facility
Manufactured to Meet RoHS & REACH Standards
Magnet Description
Our small 1/2 x 1/4 x 1/32 inch grade N52 rare earth neodymium block magnets are a strong and versatile solution for your lightweight magnetic needs. With a pull force of 1.15 lbs, these small but powerful magnets have a broad range of applications including magnet motors/sensors, robotics, craft projects, and woodworking to name a few!
These block magnets are also ideal for industrial and business applications such as 3D printing and injection molding. Their high quality and precision manufacturing guarantees that they provide superior magnetic strength and performance even in demanding environments.
Made from high-quality rare earth neodymium material, these magnets are engineered to last. They are resistant to corrosion and demagnetization, making them a reliable long-term investment.
If you are looking for a dependable magnet that is small but mighty, our 1/2 x 1/4 x 1/32 inch N52 rare earth neodymium magnets are a great choice.
- Magnet Safety Information
- RoHS/REACH Compliance
- 30 Day Return Policy
- Specification Sheet (PDF) (opens in a new tab)
- Technical Drawing (PDF) (opens in a new tab)
- 3D CAD Model (STEP)
Dimensions are nominal; see the drawing for tolerances. STEP files open in SolidWorks, Fusion, Onshape, FreeCAD and most other CAD software.
