Featured product
Learning Center2 x 1 x 1/8 Inch Large Neodymium Rare Earth Block Magnets N42 (5 Pack)
2 x 1 x 1/8 Inch Large Neodymium Rare Earth Block Magnets N42 (5 Pack)
Buy More and Save up to 35%
| Quantity of Packs | Price per Pack | Discount |
|---|---|---|
| Buy 2 | $34.01/pack | 5% Off |
| Buy 3 | $32.22/pack | 10% Off |
| Buy 5 | $30.43/pack | 15% Off |
| Buy 10 | $28.64/pack | 20% Off |
| Buy 25 | $26.85/pack | 25% Off |
| Buy 50 | $25.06/pack | 30% Off |
| Buy 100 | $23.27/pack | 35% Off |
Need more than 100 packs? Email us for a quote.
Magnet Specifications
| Imperial Size | 2.00 x 1.00 x 0.125 Inch (Length x Width x Thickness) |
|---|---|
| Metric Size | 50.8 x 25.4 x 3.175 mm (Length x Width x Thickness) |
| Material Grade | N42 |
| Pull Force | 21.9 lbs |
| Coating | Nickel-Copper-Nickel (Ni-Cu-Ni) |
| Magnetization Direction | Thickness |
| Magnet Material | Sintered Neodymium (NdFeB) |
| Tolerance | +/- 0.004 Inches |
| Max Operating Temperature | 80°C / 176°F |
| Surface Field | 1,152 Gauss |
| Flux Density (Br) | 13,300 Gauss |
| Magnet Weight | 31.1 Grams |
| Part Number | B2X1X18N42-5PK |
| Quantity Included | 5 Block Magnets |
Produced in an ISO 9001 Facility
Manufactured to Meet RoHS & REACH Standards
- Magnet Safety Information
- RoHS/REACH Compliance
- 30 Day Return Policy
- Specification Sheet (PDF) (opens in a new tab)
- Technical Drawing (PDF) (opens in a new tab)
- 3D CAD Model (STEP)
Dimensions are nominal; see the drawing for tolerances. STEP files open in SolidWorks, Fusion, Onshape, FreeCAD and most other CAD software.
Cross-Reference Part Numbers: BY0X02
Other companies' part numbers that match this magnet's published grade, size, coating and features. Not affiliated or endorsed; please confirm fit for your application.
