Learning Center5/16 x 1/32 Inch Neodymium Rare Earth Disc Magnets N52 (200 Pack)
5/16 x 1/32 Inch Neodymium Rare Earth Disc Magnets N52 (200 Pack)
Buy More and Save up to 35%
| Quantity of Packs | Price per Pack | Discount |
|---|---|---|
| Buy 2 | $25.46/pack | 5% Off |
| Buy 3 | $24.12/pack | 10% Off |
| Buy 5 | $22.78/pack | 15% Off |
| Buy 10 | $21.44/pack | 20% Off |
| Buy 25 | $20.10/pack | 25% Off |
| Buy 50 | $18.76/pack | 30% Off |
| Buy 100 | $17.42/pack | 35% Off |
Need more than 100 packs? Email us for a quote.
Magnet Specifications
| Imperial Size | 0.3125 x 0.03125 Inch (Diameter x Thickness) |
|---|---|
| Metric Size | 7.937 x 0.79 mm (Diameter x Thickness) |
| Material Grade | N52 |
| Pull Force | 0.9 lbs |
| Coating | Nickel-Copper-Nickel (Ni-Cu-Ni) |
| Magnetization Direction | Axially |
| Magnet Material | Sintered Neodymium (NdFeB) |
| Tolerance | +/- 0.004 Inches |
| Max Operating Temperature | 80°C / 176°F |
| Surface Field | 1,451 Gauss |
| Flux Density (Br) | 14,800 Gauss |
| Magnet Weight | 0.3 Grams |
| Part Number | D516X132N52-200PK |
| Quantity Included | 200 Disc Magnets |
Produced in an ISO 9001 Facility
Manufactured to Meet RoHS & REACH Standards
- Magnet Safety Information
- RoHS/REACH Compliance
- 30 Day Return Policy
- Specification Sheet (PDF) (opens in a new tab)
- Technical Drawing (PDF) (opens in a new tab)
- 3D CAD Model (STEP)
Dimensions are nominal; see the drawing for tolerances. STEP files open in SolidWorks, Fusion, Onshape, FreeCAD and most other CAD software.
Cross-Reference Part Numbers: D501-N52, D032B2-N52
Other companies' part numbers that match this magnet's published grade, size, coating and features. Not affiliated or endorsed; please confirm fit for your application.
